Physical
Cantilever: Solid Boron Rod: 0.28 mm diameter
Stylus: Nude line - contact diamond, mirror polished
Stylus tip radius: 3x 60um,
Vertical tracking angle (VTA): 20 degrees
Coil: Pure iron cross
Weight: 8. Grams
Electrical
Output voltage: 0.8mV at 3.54 cm/s
Internal impedance: 24 ohms
Frequency response: 20 - 20000Hz +- dB
Channel balance: Better than 0.5 dB
Channel separation: Better than 35 dB at 1kHz
Dynamic
Dynamic Tracking ability at 315 Hz at a tracking force of 2 grams: 80Um
Dynamic compliance: 15 um/mN
