Physical
Cantilever: Solid boron rod: 0.28 mm diameter
Stylus: Nude line-contact diamond, mirror polished
Stylus tip radius: 3 x 60um
Vertical tracking angle (VTA): 20 degrees
Coil: Pure iron cross
Weight 8.8 grams
Electrical
Output voltage: 0.4 mV at 3.54 cm/s
Internal impedance: 12 Ohms
Frequency Response: 20 - 20,000HZ +- 1 db
Channel balance: Better than 0.5 dB
Channel separation: Better than 35 dB at 1kHz
Dynamic
Tracking ability at 315 Hz at a tracking force of 2 grams: 80um
Dynamic compliance: 15 um/mN
